At Metal Forge India, we take satisfaction in being a leading flanges manufacturer in India, presenting top-notch, quality, and precision-engineered products. As an ISO 9001:2015 licensed organization, we strictly follow global standards and industry recommendations to provide our clients with flanges that ensure average overall performance, durability, and protection.
In this blog, we’ll explain what a flange is and discover the 7 most common types of flanges used throughout industries. If you’re looking for all types of flanges available under one roof, this guide is only for you.
What is a Flange?
A flange is a mechanical tool used to connect pipes, valves, pumps, and distinctive gadgets in a piping machine. It acts as a turning into a member of a factor among components, making the system clean to assemble, disassemble, or test out.
Flanges are commonly welded or screwed into the piping system, after which they are joined with bolts. They are widely applied in industries like oil and gasoline, petrochemicals, power plants, water treatment, and more.
Why Are Flanges Important?
Flanges offer:
- Strong and leak-proof connections
- Ease of protection and inspection
- Better alignment for piping structures
- Resistance to excessive strain and temperature
As we are the flanges manufacturer in India, we manufactured flanges that meet international requirements like ANSI, ASME, DIN, EN, and BS to healthful numerous commercial applications.
7 Common Types of Flanges
Let’s test the seven most commonly used flange types and their programs.
-
Weld Neck Flange
Weld Neck Flanges have a prolonged tapered hub and are welded to the pipe. They are excellent for excessive-strain and immoderate-temperature packages.
Applications:
- Oil and gas pipelines
- Power technology
- Chemical Plant
Key Benefit: Smooth waft transition and decreased pressure at the bottom.
-
Slip-On Flange
Slip-on flanges are easy to install and slide over the pipe before being welded from each facet.
Applications:
- Low-pressure systems
- Cooling water lines
- Firefighting systems
Key Benefit: Cost-effective and simple to align.
-
Blind Flange
Blind Flanges are used to shut the valve of a piping machine or a pressure vessel.
Applications:
- Testing pipe glide
- Isolating systems
- Temporary or permanent closure
Key Benefit: Strong seal with 0 leakage.
-
Socket Weld Flange
Socket Weld Flanges have a socket in which the pipe is inserted and then welded. They are used for small-diameter, extreme-pressure pipes.
Applications:
- Hydraulic systems
- Steam traces
- Chemical piping
Key Benefit: Internal welding prevents leakage.
-
Threaded Flange
These flanges have threads and are screwed onto the pipe in place of being welded, making them best for non-welded connections.
Applications:
- Low-pressure systems
- Hazardous environments (in which welding is risky)
- Water and gasoline pipelines
Key Benefit: No welding wished; clean installation.
-
Lap Joint Flange
Lap Joint Flanges are used with a stub end and are tremendous for structures that require common dismantling.
Applications:
- Food processing
- Pharmaceutical structures
- Water Treatment plants
Key Benefit: Easy to align and disassemble.
-
Orifice Flange
Orifice flanges are designed for use with orifice meters for measuring waft charge in a pipeline.
Applications:
- Process control systems
- Oil and gasoline metering
- Chemical glide evaluation
Key Benefit: Enables particular waft measurement.
All Types of Flanges Available at Metal Forge India
Whether you want Weld Neck, Slip-On, Blind, or any specialized form of flange, we have all types of flanges available under one roof. We manufacture flanges in numerous materials, such as:
- Stainless Steel
- Carbon Steel
- Alloy Steel
- Duplex and Super Duplex
- Nickel Alloys
Each flange is carefully tested and authorized for excellent, stress resistance, and dimensional accuracy.
Why Choose Metal Forge India?
Here’s why we’re the preferred flanges manufacturer in India:
- ISO 9001:2015 Certified
- Customization Available
- Global Standards (ASME, ANSI, DIN, and so on.)
- Experienced Team and Advanced Technology
- Competitive Pricing and Fast Delivery
- All Types of Flanges Available in numerous sizes and substances
We serve industries all through the globe, turning in excellence one flange at a time.
Conclusion: Your Trusted Flange Partner
To summarize, flanges are important additives in piping systems that help in becoming a member of, sealing, and retaining glide. The seven sorts of flanges serve particular functions based totally on stress, temperature, and the nature of the fluid.
Metal Forge India, a top-rated flanges manufacturer in India, is your depended-on companion for great and precision. With all types of flanges available, we’re right here to aid your business dreams with dependable answers.
